Fashion Production Drawing: Womens Puffer Short Jacket

Following direction from the designer and several physically produced samples, I drew this puffer vest form in Illustrator showing all stitch lines, seams, pockets and closures. I also created a version showing the hood pulled out from a zipper collar compartment, and I created a close-up detail of the jacket pocket with measurements. All final image versions were then entered into a packet program along with all the measurements and other relevant information needed to produce this piece of clothing, and the packet was sent to the overseas production factory for physical sampling.

(5 representative images below)
